Fox FX Series Oil Water Separators
Fox Environmental Systems Oil Water Separator range is designed for all types of waste water treatment applications. These systems provide solutions for companies generating waste water that will require treatment before disposal to the council’s sewer and commercial car wash re-use systems.
Fox Oil Water Separators proudly manufactured in Australia
Proudly manufactured in Australia and made from quality stainless steel Fox Oil Water Separators are renowned for their Quality, Performance and Endurance. To ensure total performance, service ability and discharge quality, Fox Enviro use the Vertical Tube Coalescing Filters technology (VTC) in all Oily Water Separator Systems as well as 100 micron Filter bags in the FX1000SS, FX1500SS, and FX3000SS Systems.
All Oil Water Separators are packaged to suit biosecurity, and local Council requirements and are supplied complete with pump, poly 20 litre waste oil drum, float switches and low voltage controllers.
Oil Water Separator Applications
- Automotive workshops
- Car dealerships
- Panel beaters
- Shipping Container Wash Bays
- AQIS (Bio Security) Wash Bays
- Mechanical workshops
- Plant and equipment hire
- Fuel stations
- All mechanical wash bays
Available Flow Rates – 1000 / 200,000 L/PH
Custom Units available. Contact us for details.
Compare Oil Water Separator Models
| Model | Max Flow Rate (L/h) | Inlet Size | Outlet Size | Gate Valve | Weight Empty | Weight Full | Specifications |
|---|---|---|---|---|---|---|---|
| FX1000SS | 1000 | 40mm BSP Female | 50mm BSP Female | 40mm BSP Male | 44kg | 165kg | 📄 Download Spec Sheet 📄 Download FXP 1000 Diaphragm Pump Spec Sheet |
| FX1500SS | 1500 | 40mm BSP Female | 50mm BSP Female | 40mm BSP Male | 56kg | 220kg | 📄 Download Spec Sheet 📄 Download FXP 1500 Diaphragm Pump Spec Sheet |
| FX3000SS | 3000 | 40mm BSP Female | 50mm BSP Female | 2 x 40mm BSP Male | 80kg | 430kg | 📄 Download Spec Sheet |
| FX6000SS | 6000 | 2 x 65mm BSP Female | 100mm BSP Female | 2 x 40mm BSP Male | 245kg | 1170kg | 📄 Download Spec Sheet |
| FX10000SS | 10000 | 2 x 80mm BSP Female | 2 x 100mm BSP Female | 4 x 50mm BSP Male | 340kg | 2240kg | 📄 Download Spec Sheet |
| FX15000SS | 15000 | 2 x 80mm BSP Female | 2 x 100mm BSP Female | 4 x 50mm BSP Male | 590kg | 2935kg | 📄 Download Spec Sheet |
| FX20000SS | 20000 | 2 x 80mm BSP Female | 2 x 100mm BSP Female | 4 x 50mm BSP Male | 590kg | 3630kg | 📄 Download Spec Sheet |
| FX30000SS | 30000 | 2 x 80mm BSP Female | 2 x 100mm BSP Female | 4 x 80mm BSP Male | 740kg | 4090kg | 📄 Download Spec Sheet |
Low-Voltage Pump/Control Box: Automates pump operation, featuring:
- On/Off auto selector switch
- An hour run meter ((X3 model only) to track runtime)
- A high-level alarm (top, amber-colored) for alert visibility
- Safety warnings and labels for electrical hazard control
Float Switches (Blue & Yellow): These detect water levels inside the separator tank and automatically trigger the pump to turn on/off, preventing overflows or dry running.
All Fox oil separator units are supplied with matching diaphragm pumps and smart control systems, ensuring precise flow handling in oily wastewater treatment and stormwater runoff environments.
- Diaphragm pump: Ideal for transferring oily wastewater and sludge to an oil separator.
- Non-emulsifying operation: Prevents oil and water from blending, which helps maintain clear separation and simplifies treatment.
- Self-priming: Works even in low water level conditions or dry starts.
- Corrosion-resistant materials: Built to withstand harsh trade waste environments.
Related Systems
- First Flush Systems – for pollutant diversion at the source
- Gross Pollutant Traps – for large debris interception
- Compare all stormwater treatment systems in our full product range
Need a Certified Oil Water Separator for Trade Waste, Wash Bays, or Stormwater Applications?
Fox Oil Water Separators deliver reliable hydrocarbon removal and environmental compliance for industrial wash bays, fuel handling areas, and commercial sites. Contact us to discuss a system designed for your site’s specific needs.
